JJR, a leading manufacturer in China, offers wholesale Full-Height Turnstiles crafted from SUS304 brushed stainless steel. The products feature seamless welding and polishing without deformation or color difference. The housing is precision-processed using laser cutting, equipped with hydraulic dampers for shock absorption, and includes fire signal inputs. The turnstiles are built with a self-developed plug-in mechanism and provide fail-safe unlocking without power.
Features of Full-Height Turnstile
1. Multiple Passage Modes
- Bi-directional card swiping
- One-way card swiping with free passage on the other side
- Bi-directional free passage (manual)
2. Automatic Reset Function
- If no passage is detected within the set time after unlocking, the system automatically cancels the user's access rights. The reset time is adjustable (default: 5 seconds).
3. Passage Indicator Function
- Clear direction indicators with intuitive lights signal whether passage is allowed or denied.
4. Smart Rotating System
- The intelligent rotation system ensures precise and reliable locking and unlocking at zero position.
5. Anti-Collision Function
- When no unlocking signal is received, the gate remains locked and cannot be forcibly pushed open.
6. Standardized External Ports
- Compatible with various management devices, allowing remote control and management via a central computer.
7. Stable and Safe Operation
- Hydraulic buffering ensures smooth and quiet operation.
8. Waterproof and Sunproof
- High-quality stainless steel construction offers resistance to water, sunlight, corrosion, and high temperatures.
Applications of Full-Height Turnstile
Ideal for intelligent access management at:
- Stations
- Construction sites
- Airports
- Ports
- Prisons
- Factory campuses
Technical Specifications of Full-Height Turnstile
- Material: 304 Stainless Steel
- Input Power: AC220 ±10% V, 50Hz
- Output Power: 24V/3.5A DC
- Drive Mode: 24V Electromagnetic Valve
- Working Temperature: -20°C ~ 60°C
- Relative Humidity: ≤90%, non-condensing
- Unlock Signal: Passive signal (relay dry contact signal)
- Communication Interface: RS485
- Passage Width: ≤650mm
- Passage Speed: ≤35 persons/minute
- Application Scope: Indoor or outdoor
- Power Consumption: 50W
Dimensions:
- DR.TD.6772-1: 1550×1350×2300 mm (Clearance: 2000mm)
- DR.TD.6772-2: 2530×1450×2300 mm (Clearance: 2000mm)
